PDU 12P 10A 200-240V

Cloud Managed 2U 10A Smart PDU with 12 Metered Outlets

ECP212-INT

Product Highlight

The EnGenius Cloud Managed 2U 10A Smart PDU with 12 IEC-C13, PDU 12P 10A 200-240V (ECP212-INT) serves as a cloud-based power management solution for diverse applications. It facilitates remote and local control, efficient energy management, and advanced surge protection. Additionally, it offers unified management for all EnGenius devices, simplifying maintenance and troubleshooting by enabling power cycling of multiple devices. Function
  • Real-time power consumption monitoring and alarming per outlet
  • Remote switching per outlet
  • 1.3 inches display for visualizing power information
  • Attempt to automatically reconnect from internet outages
  • Local and cloud management with analytic reports
Safety
  • 12A circuit breaker from overloading protection
  • Fire proof MOV and grounded protection
  • UL 62368-1, CE, RCM
Integration
  • RESTFUL API supported
  • SNMP v1 2c 3 supported

Product Intro Video

Environmental & Physical

Physical Interfaces

2 x 10/100/1000 BASE-T
IEC-C13 Inletbr
Rest Button
12A Circuit Breaker

Operating Temperature

Operating: 0°C ~ +45°C

Storage Temperature

Storage: -30°C ~ +70°C

Storage Humidity

Humidity 5% ~ 95% RH Non-condensing

Surge Protection

Yes

ESD Protection

Yes

Dimensions & Weight

Weight

2460 g

Dimensions

440 x 88 x 101.9 mm

Enclosure material

SECC

Package Contents

1 – ECP212-INT PDU
1 – Inlet Power Cord
2 – C14 to C13 Plug Adapter
1 – Mounting Brackets
4 – Rubber Feet Cushion
8 – M4x6 Screws
4 – T4x19 Screws
4 – Spacer
1 –Drywall Anchor Kit
1 –Retention Clip

Compliance & Warranty

Safety Compliance

UL 62368-1

WEEE

Yes

RoHS

Yes

Regulatory Compliance

CE
RCM

Model Comparison

PDU 12P 10A 200-240V

PDU 6P 10A 200-240V

Model Number ECP212-INT ECP106-INT
Dimensions 440 x 88 x 101.9 mm 440 x 44 x 85 mm
Weight - -
Enclosure Material SECC AL6063
Networking Interfaces (2) 10/100/1000 BASE-T (2) 10/100/1000 BASE-T
Management Interface Ethernet Ethernet
VSWR (12)IEC-C13, 200-240V AC, 10A max.,50/60Hz (6)IEC-C13, 200-240V AC, 10A max.,50/60Hz
Power Method 200-240VAC, 10A max.,50/60Hz 200-240VAC, 10A max.,50/60Hz
Max. Power Consumption 2400W for 240VAC 2400W for 240VAC
Buttons (1) Factory Reset
(1) Circuit Breaker
(1)Outlet Power Button
(2)LCD Control Buttons		 (1) Factory Reset
(1) Circuit Breaker
(1)Outlet Power Button
(2)LCD Control Buttons
Protection Surge Protection
Gounded Protection		 Surge Protection
Gounded Protection
LCM Display 1.3 RGB display, Non-touch
Firmware Upgradable 		1.3 RGB display, Non-touch
Firmware Upgradable
Operating Temperature Operating: 0°C ~ +45°C Operating: 0°C ~ +45°C
Operating Humidity Humidity 5% ~ 95% RH Non-condensing Humidity 5% ~ 95% RH Non-condensing
Certifications CE,RCM,UL 62368-1 CE,RCM,UL 62368-1
