FitGateway6 4G 1SFP

EnGenius FitXpress VPN 防火牆，配備 4 組 Gigabit（1 組 PoE+）乙太網路埠與 1 組 SFP 埠

XG60-FIT

Product Highlight

EnGenius Fit VPN 路由器 XG60-FIT 提供具有高級功能的高性能網路解決方案，包括負載平衡、雙 WAN 和站點到站點 VPN。此產品透過 FitXpress 提供統一管理，可以在任何地方輕鬆配置和管理。它為尋求增強網路性能和安全性的企業提供全面的點對點解決方案。

簡單且統一的 FitXpress 管理，適用於任何規模的企業

隨時隨地可進行直覺且集中式的設備可視化管理

雙 GE WAN 和雙 GE LAN 實現最佳性能

WAN: 1個 GE RJ45, 1個可轉換 GE RJ45 LAN/WAN Port, USB 3.1

LAN: 2個GE RJ45, 1個可轉換 GE RJ45 LAN/WAN Port , 1個SFP

雙核心 2.1 GHz 處理器提供更高的速度和功率

雙廣域網埠(WAN port)支援負載平衡和故障備援

PoE+埠為 Wi-Fi AP、IP 攝影機或 IP 電話供電

具有高效過濾和檢查功能的網路狀態防火牆可增強安全性

高性能且安全的站點到站點VPN和客戶端VPN

快速自我修復 VPN 和 VLAN 設置，實現更快、更輕鬆的佈署

非接觸式系統維護和自動更新

多種直通模式和路由選項

具有外部使用者遠端驗證服務的網路入口

Product Intro Video

Hardware

CPU Processor

Dual Core

Operating Frequency

2.1GHz

Memory

4 GB

Flash Storage

8 GB

RJ-45 Interface

4x GE

SFP interface

1

PoE port

1x GE RJ45 LAN Port (802.3 af/at)

USB 3.1

1 (Cellular)

Console

1 (RJ-45)

Interface

WAN: 1x GE RJ45, 1x Covertible GE RJ45 LAN/WAN Port
LAN: 2x GE RJ45, 1x Covertible GE RJ45 LAN/WAN Port , 1xSFP
1x Cellular USB 3.1

Perfomance & Capacity

Firewall (SPI throughput)

3 Gbps

VPN throughput

900 Mbps

Max. Concurrent VPN Tunnels

8

Max. Concurrent VPN Users

50

Max. TCP Concurrent sessions

1,000,000

Max VLANs

16

Clients

<100 is recommended

Network & Security

WAN Connecttion

DHCP/PPPoE/Static IP
Failover
Load balance

Security

Stateful Firewall
Virtual Server (Port Forwarding)
IPSec Site-to-Site AutoVPN
IPSec Client VPN

Other functions

VLAN Tagging
EnGenius DDNS
DHCP server

Environmental & Physical

Operation Temperature

0°C to 40°C

Humidity (non-condensing)

5 to 95% non-condensing

Power

54V/1.2A

Dimensions & Weight

Dimensions

210×179.5x35mm

Package Contents

Power adapter
Power cord
RJ-45 Console Cable
Wall Mount Kit / Rubber foot
Product Card

Regulatory Compliance

FCC Part 15 (Class B)
IC
CE EMC
CB
UL

Related Products

Downloads

類型	檔名	Version	Release Date	Checksum
Data Sheet	規格手冊_FitGateway6 4G 1SFP_XG60-FIT Datasheet	v1.4	22 12 月, 2025
Brochure	簡介手冊_EnGenius Fit Solution Brochure	v1.0	30 11 月, 2023
Quick Guide	快速入門指南_FitGateway6 4G 1SFP_XG60-FIT_QSG_EN	v1.0	05 1 月, 2026
Firmware	FitGateway6_4G1SFP_XG60-FIT_firmware_v1.0.21-1.bin	v1.0.21	21 1 月, 2025	× Checksum MD5 daea63cb6f3ddd8f94cf9714fabe4992 SHA2 41b230cfbcd33bad9a9586f0b226b795216871133ce915e1bc7dc67ca0fc50bc Close
