CloudSwitch L2Plus 24 PoE
EnGenius クラウド管理型レイヤー2+ スイッチ ECS1528Pは、24のギガビットPoE+ポート、4つの10G SFP+アップリンクポート、240WのPoEバジェットを備え、中小企業に最適です。ゼロタッチプロビジョニングとクラウドによる集中管理をサポートし、ネットワークの展開と運用を効率化します。 高度なセキュリティ機能、Voice-VLAN、PoE拡張モードに加え、PoE自動リブートやアップグレード中の給電継続機能を備え、高品質の音声および監視トラフィックの安定運用を実現。コストパフォーマンスに優れた中小企業向けネットワークインフラを提供します。
802.3 10Base-T Ethernet
802.3u 100Base-TX Ethernet
802.3ab 10000Base-T Ethernet
802.3x Full-Duplex Flow Control
(24)10/100/1000 Mbps Ports
Switching Capacity: 128Gbps
Forwarding Mode: Store-and-Forward
Flash Memory: 128 MB
SDRAM: 512MB
Packet Buffer Memory: 1.5 MB
Address Database Size: 16K MAC Addresses
PoE Standard: Ports 1~8 Support IEEE 802.3af/at
PoE Capable Ports: All Gigabit Ethernet Ports
240W
AC Input: 100 ~ 240VAC, 50-60Hz, 1.2A
DC Output: 54V/1.67A
Power LED
Fault LED
PoE Max LED
LAN Mode LED
PoE Mode LED
Link/Activity/Speed (per Ethernet port)
Link/Activity/Speed (per SFP slot)
EnGenius Cloud
Local Web GUI
16K
10K
Max 256 groups
MLD Snooping: v1
Cos/802.1p
DSCP
CoS/802.1p-DSCP
Strict / WRR/ Strict + WRR
Port-based bandwidth control (Ingress/Egress)
Max. 256 Entries
MAC Based ACL
IPv4/IPv6 Based ACL
ACL Binding
HTTP IPv4 / IPv6
HTTPS IPv4 / IPv6
SNMP v1/v2c/v3 Support
RMON 1,2,3,9
Time Setting/Daylight saving
802.1D Spanning Tree
802.1w Rapid Spanning Tree
802.1S Rapid Spanning Tree
Loopback Detection
Multicast Filitering
IGMP Snooping
802.1Q VLAN tagging
802.3x flow control
802.3ad Link Aggregation
IPv4 DHCP Relay
IPv4 DHCP Snooping
IPv4 DHCP Snooping Source MAC Address Check-up
ARP Packet Validation (additional validation checks)
Voice VLAN
Port-based VLAN
CoS Mapping
802. 1X Radius Authentication Protocol
IPv4 Settings/ IPv6 Settings
IEEE 802. 3az Energy Efficeient Ethernet (EEE)
Command Line Interface (CLI)
SSH Server
Telnet Server
TFTP Client
Configuration Upgrade/ Backup
Simple Network Time Protocol (SNTP)
SYSLOG
20 IPv6 address
Max. 192 ARP entries
Max. 63 entries
Max. 21 entries
Operating: 32 to 122° F/0 to 50° C
Storage: -4 to 158° F/-20 to 70 ° C
5% – 95%
Weight: 4.7 Kg
Width: 260 mm
Length: 440 mm
Height: 44 mm
1x Cloud Managed Gigabit Switch
1x Product Card
1x Power Cord
1x RJ45 Console Cable
1x Rack Mount Kit
