AI NVS 4Bay Tower

4-Bay AI 雲端網路影像伺服器(NVS)

EVS1004D

Product Highlight

EVS1004D 為一款精巧型 4Bay 直立式 AI-NVS,專為將既有 ONVIF/RTSP 攝影機升級為智慧監控系統而打造。透過 GPU 加速的 Edge AI 運算與 Cloud AI 整合,系統可對所有已連接攝影機提供具情境感知能力的事件偵測與即時監控。 內建企業級 RAID 1/5/6 儲存架構,確保高可用性錄影與持續性資料保護。透過雲端集中管理,並支援智慧搜尋與時間軸導覽功能,EVS1004D 可在不更換既有攝影機的前提下,實現企業級監控部署。

  • 雲端儀表板集中管理與行動 App 即時監控,隨時隨地掌握影像狀態
  • GPU 加速 Edge AI 運算與 Cloud AI 整合
  • 支援 ONVIF/RTSP 第三方攝影機接入
  • 4 個硬碟插槽,支援 3.5 吋或 2.5 吋 HDD
  • 支援 RAID 1/5/6 資料保護機制

Technical Specifications

System

Max 3rd-Party Cameras

16 cameras

Camera Resolution

FHD, 4MP, 5MP, 4K

Camera Interface

ONVIF Profile S, RTSP, EnGenius

RAID

RAID 1/5/6

Storage Retention

24/7 seamless recording and retention

Max AI Empower

2 cameras

Max EnGenius Cameras (Storage)

30 EnGenius cameras

Hardware

Processor

Intel Elkhart Lake x6211E

Memory

8GB

Flash

16GB

Security

TPM v2.0

Drive Interface

SATA 3.0 x 4

Networking Interface

10GbE RJ45 x 1, 1GbE RJ-45 x 1

Display

HDMI 1.4b x 1

USB Port

.0 Type A x 4, 2.0 Type A x 1

FAN Speed Control

Yes

Thermal Sensor

System x 1, CPU x 1

Buzzer

Yes

Button

Power, Function

LED Indicator

Power x 1, Function x 1, HDD x 4

Power Supply

[email protected]

Max. Power Consumption

140W

Ambient Operating Temperature

0~50°C (32~122°F)

Ambient Operating Humidity

10~85% RH

Advanced AI Analytics

People Detection and Tracking

Event detection, Smart Motion Search, People Counting

Vehicle Detection and Tracking

Event detection, Smart Motion Search, Vehicle Counting

EnGenius Cloud AI

Natural Language Search, Contextual AI Analysis, SD-Alert

Mechanical

Kensington Slot

Yes

Enclosure Material

Aluminium alloy, Polycarbonate

Dimensions (L x W x H)

179.6 x 227.5 x 157.0 mm

Weight

2.647Kg

Management Software

Web Browser

Chrome, Safari, Edge

Mobile App

Cloud To-Go on iOS and Android

Model Comparison

AI NVS 4Bay Tower

Model Number EVS1004D
Form Factor Compact Tower
Max 3rd-Party Cameras infoUp to the indicated quantity. Actual capacity depends on other enabled features and system configuration. 16
Max AI Empower infoUp to the indicated quantity. Actual capacity depends on other enabled features and system configuration. 2
Max EnGenius Cameras (Storage) infoUp to the indicated quantity. Actual capacity depends on other enabled features and system configuration. 30 EnGenius cameras
Storage Capacity 4 Bays
Data Protection RAID 1/5/6
