New
Fit6 2×2 Outdoor

EnGenius Fit 802.11ax 2x2 雙頻室外無線基地台

EWS850-FIT

Product Highlight

EnGenius Fit6 2x2 室外無線基地台為您的室外空間帶來 Wi-Fi 6,最高速度可達 574 Mbps/2.4 GHz 和 1,200 Mbps/5GHz,提供無與倫比的性能。其 IP67 防水外殼可提供保護,高增益天線確保您即使在最偏遠的地方也能保持連接,而不會因 WPA3/WPA2-PSK (AES) 加密功能而犧牲安全性。

  • 雙發式 802.11ax 架構且向下兼容 ac/a/b/g/n 客戶端設備
  • 360° 全向天線可在普遍環境下實現網路客戶端設備的全面覆蓋
  • 5 dBi 集成 2x2 天線
  • 支援高達 1,200 Mbps 在 5GHz 頻段 & 574 Mbps 在 2.4GHz 頻段
  • x 2.5GE PoE+ 連接埠為靈活的電源選項
  • 符合專有 48V PoE 輸入,以實現靈活安裝並在超過 100 公尺 (328 英尺) 的距離遠程重置/重啟無線基地台
  • 帶有 IP67 防護等級的堅固外殼,可在極端天氣下部署。
  • 支援 WPA3 和 WPA2-AES 認證
  • 通過 FitController 控制器進行本地和遠端管理,無需費用

Product Intro Video

Technical Specifications

Standard

802.11a/b/g/n/ac/ax

Antenna

4 x 2.4 GHz: 5 dBi
4 x 5 GHz: 5 dBi

Physical Interface

1 x 10/100/1000/2500 BASE-T

LED Indicators

1 x Power
1 x LAN
1 x 2.4 GHz
1 x 5 GHz

Power Source

PoE 802.3af/at

Maximum Power Consumption

15.9W

Wireless & Radio Specifications

Operating Frequency

Dual-Radio Concurrent 2.4 GHz & 5 GHz

Operation Modes

Managed mode: AP, AP Mesh, Mesh

Frequency Radio

2.4 GHz: 2400 MHz ~ 2482 MHz
5 GHz: 5150 MHz ~ 5250 MHz, 5250 MHz ~ 5350 MHz, 5470 MHz ~ 5725 MHz, 5725 MHz ~ 5850 MHz

Transmit Power

Up to 23 dBm on 2.4 GHz
Up to 25 dBm on 5 GHz
(Maximum power is limited by regulatory domain)

Tx Beamforming (TxBF)

Radio Chains

2 × 2:2

SU-MIMO Capability

Two (2) spatial stream Single User (SU) MIMO for up to 574 Mbps wireless data rate with HE40 bandwidth to a 2×2 wireless client device under the 2.4GHz radio.
Two (2) spatial stream Single User (SU) MIMO for up to 1,200 Mbps wireless data rate with VHT80 to a 2×2 wireless device under the 5GHz radio.

MU-MIMO Capability

Two (2) spatial streams Multiple (MU)-MIMO up to 1,200 Mbps wireless data rate for transmitting to two (2) streams MU-MIMO 11ax capable wireless client devices under 5GHz simultaneously.
Two (2) spatial streams Multiple (MU)-MIMO up to 574 Mbps wireless data rate for transmitting to two (2) streams MU-MIMO 11ax capable wireless client devices under 2.4GHz simultaneously.

Supported Data Rates (Mbps):

802.11ax:
2.4 GHz: 9 to 574 (MCS0 to MCS11, NSS = 1 to 2)
5 GHz: 18 to 1200 (MCS0 to MSC11, NSS = 1 to 2)
802.11b: 1, 2, 5.5, 11
802.11a/g: 6, 9, 12, 18, 36, 48, 54
802.11n: 6.5 to 300 Mbps (MCS0 to MCS15)
802.11ac: 6.5 to 867 Mbps (MCS0 to MCS9, NSS = 1 to 2)

Supported Radio Technologies

802.11ax: Orthogonal Frequency Division Multiple Access(OFDMA)
802.11a/g/n/ac: Orthogonal Frequency Division Multiple (OFDM)
802.11b: Direct-sequence spread-spectrum (DSSS)

Channelization

802.11ax supports high-efficiency throughput (HE) —HE 20/40/80 MHz
802.11ac supports very high throughput (VHT) —VHT 20/40/80 MHz
802.11n supports high throughput (HT) —HT 20/40 MHz
802.11n supports high throughput under the 2.4GHz radio –HT40 MHz (256-QAM)
802.11n/ac/ax packet aggregation: A-MPDU, A-SPDU

Supported Modulation

802.11ax: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM, 1024-QAM
802.11ac: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM
802.11a/g/n: BPSK, QPSK, 16-QAM, 64-QAM
802.11b: BPSK, QPSK, CCK

Max Concurrent User

128 per radio

Management Features

Deployment Options

Stand-Alone (Individually Managed)
FitXpress
FitController

Environmental & Physical

Temperature Range

Operating: -4º~140ºF/-20ºC~60ºC
Storage: -40Fº~176ºF/-40ºC~80ºC

Humidity (non-condensing)

Operating: 0%~90% typical
Storage: 0%~90% typical

Dimensions & Weight

EWS850-FIT Device

Length: 190 mm
Width: 124 mm
Height: 47 mm

Package Contents

1 – EWS850-FIT Outdoor Access Point
2 – Pole-Mounting Brackets
1 – Wall-Mount Screw Set
2 – 2.4GHz 5dBi SMA Antennas
2 – 5GHz 5dBi SMA Antennas
1 – Quick Installation Guide
1 – EPA5006GR PoE Injector

Compliance

FCC
CE
IC
UCKA

Warranty

2 Year
