Cam8MP Dome IP67 512GB
EnGenius Cloud Camera Cam8MP Dome IP67 512GB（ECC500）搭載 AI 人臉辨識功能，可協助企業即時辨識人員、接收即時警示，並快速找到相關錄影畫面。內建 512GB 儲存空間，可直接於地端進行可靠的 4K 影像錄製，降低對傳統 NVR 或持續上傳雲端的依賴，同時讓中小型企業對敏感監控資料擁有更高的掌控度。搭載 800 萬畫素 Sony STARVIS 感光元件、HDR、延伸紅外線照明距離，以及 IP67 防塵防水與 IK10 防暴等級，為要求嚴苛的室內與戶外環境提供智慧且可靠的安全監控。
V1.0
1/2.8 “ Sony Starvis 8MP CMOS
Varifocal 3.2 ~ 10.5mm motorized zoom, Remote zoom, AF
H: 108.1° ~ 30.3°, V: 56.3° ~ 17.1°, D: 130.9° ~ 34.8°
Built-in IR LED illumination and IR cut filter
30m / 98ft
Manual, Pan: 0° ~ 350°, Tilt: 0° ~ 60°, Roll: 0° ~ 350°
8MP 3840×2160 (16:9)
20 FPS
H.265, H.264, Smart Stream
600Kbps ~ 6Mbps (Optional, Adaptive)
AE, AWB, AGC, BLC, LDC, True WDR(120dB), HDR, 3DNR, Privacy Mask, OSD, Video Orientation
AAC, G.711
Built-in, 5m / 15ft distance
Not supported
Built-in
History search, People counting
History search, Vehicle counting
Event alert
Event alert, Object counting
Event alert, Object counting
Event alert
Event alert
History search, Search by Photo, Target alert, Tracking Timeline
Support
V1.0
1/2.8 “ Sony Starvis 8MP CMOS
Varifocal 3.2 ~ 10.5mm motorized zoom, Remote zoom, AF
H: 108.1° ~ 30.3°, V: 56.3° ~ 17.1°, D: 130.9° ~ 34.8°
Built-in IR LED illumination and IR cut filter
30m / 98ft
Manual, Pan: 0° ~ 350°, Tilt: 0° ~ 60°, Roll: 0° ~ 350°
8MP 3840×2160 (16:9)
20 FPS
H.265, H.264, Smart Stream
600Kbps ~ 6Mbps (Optional, Adaptive)
AE, AWB, AGC, BLC, LDC, True WDR(120dB), HDR, 3DNR, Privacy Mask, OSD, Video Orientation
AAC, G.711
Built-in, 5m / 15ft distance
Not supported
Built-in
History search, People counting
History search, Vehicle counting
Event alert
Event alert, Object counting
Event alert, Object counting
Event alert
Event alert
History search, Search by Photo, Target alert, Tracking Timeline
Support
512GB on board
24/7 seamless, Auto Recycling
30 days
AES256
Support EnGenius NVS and Cloud storage
System power and status indicator
Supported
Internal
10/100/1000 MbE RJ45 port
802.3at PoE+
16.1W
-40°C ~ 60°C / -40°F ~ 140°F
5～90％
CE, FCC
Aluminum alloy, Polycarbonate
IP67
IK10
Ø145 x 105 mm (Ø5.71x 4.14″)
740g / 26.11oz
Chrome, Safari, Edge
Cloud To-Go on iOS and Android
EnGenius Sight on Google TV
512GB on board
24/7 seamless, Auto Recycling
30 days
AES256
Support EnGenius NVS and Cloud storage
System power and status indicator
Supported
Internal
10/100/1000 MbE RJ45 port
802.3at PoE+
16.1W
-40°C ~ 60°C / -40°F ~ 140°F
5～90％
CE, FCC
Aluminum alloy, Polycarbonate
IP67
IK10
Ø145 x 105 mm (Ø5.71x 4.14″)
740g / 26.11oz
Chrome, Safari, Edge
Cloud To-Go on iOS and Android
EnGenius Sight on Google TV
Cam8MP Dome IP67 512GB |
Cam8MP Dome IP67 NS |
Cam5MP Bullet IP66 256GB |
Cam5MP Bullet IP66 |
Cam5MP Dome IP67 256GB |
Cam5MP Dome IP67 |
|
|---|---|---|---|---|---|---|
| Model Number | ECC500 | ECC500Z | ECC120 | ECC120Z | ECC100 | ECC100Z |
| Resolution | 4K | 4K | 5MP | 5MP | 5MP | 5MP |
| Field of View | H: 97° ~ 35.3° | H: 108.1° ~ 30.3° | H: 78° | H: 102° | H: 102° | H: 102° |
| Optical Zoom | 3x | 3x | - | - | - | - |
| IR Night Vision | 30m / 98ft | 30m / 98ft | 30m / 98ft | >20m / 66ft | >20m / 66ft | >20m / 66ft |
| Audio | Microphone | Microphone | - | Microphone | Microphone | Microphone |
| Object Detection and Tracking | V | Yes | - | Yes | V | Yes |
| Room Occupation | Yes | Yes | Yes | Yes | Yes | Yes |
| Hands-up Detection | Yes | Yes | - | - | - | - |
| Facial Recognition | V | Yes | - | - | - | - |
| License Plate Recognition | V | - | - | - | - | - |
| Storage | 512GB | - | 256GB | - | 256GB | - |
| Deployment | PoE | PoE+ | PoE | PoE | PoE | PoE |
| Weatherproofing | IP67 | IP67 | IP66 | IP67 | IP67 | IP67 |
| Resistance | IK10 | IK10 | - | - | IK10 | IK10 |
|
