Gateway5 4mG

雲端管理型 4埠 2.5Gigabit (1個 PoE+) Multi-G VPN防火牆

ESG510
雲端管理型VPN 防火牆 VPN 防火牆功能介紹

Product Highlight

EnGenius ESG510 VPN 路由器提供具有高級功能的高性能網路解決方案，包括負載平衡、雙 WAN 和站點到站點 VPN。該產品通過EnGenius Cloud提供統一管理，可以在任何地方輕鬆配置和管理。它為尋求增強網路性能和安全性的企業提供全面的點對點解決方案。

  • 簡單且統一的雲端管理，適用於任何規模的企業
  • 隨時隨地可進行直覺且集中式的設備可視化管理
  • 雙 2.5 GE WAN 和雙 2.5 GE LAN 實現最佳性能
  • 四核心 1.6 GHz 處理器提供更高的速度和功率
  • 雙廣域網埠(WAN port)支援負載平衡和故障備援
  • 2.5 GbE PoE+ 為 Wi-Fi 6E AP、IP 攝影機或 IP 電話供電
  • 具有高效過濾和檢查功能的網路狀態防火牆可增強安全性
  • 高性能且安全的站點到站點VPN和客戶端VPN
  • 快速自我修復 VPN 和 VLAN 設置，實現更快、更輕鬆的佈署
  • 非接觸式系統維護和自動更新
  • 多種直通模式和路由選項
  • 支持外部 Radius 的認證頁面
  • 整合 CloudBrink 服務，提供零信任網路存取（ZTNA）解決方案

Hardware

CPU Processor

Quad Core

Operating Frequency

1.6GHz

Memory

4GB

Flash Storage

8GB

RJ-45 Interface

4×2.5G

SFP Interface

–

PoE Ports

1

PoE Standard

802.3 af/at

I/O Interfaces

1 x RJ-45 console
1 x USB 3.0

Mounting Method

Wall mount

Security

TPM

Network & Security

Firewall (SPI throughput)

4G

VPN throughput

970M

Max. Concurrent VPN Tunnels

200

Max. Concurrent VPN Users

250

Max. TCP Concurrent Sessions

1,000,000

Max VLAN

96

Firewall Features

Stateful Packet Inspection
Policy Rules
Port Forwarding
1:1 NAT
Allow Inbound Services
Layer 7 Application Firewall

Site-to-Site VPN

Mesh VPN/ Hub-and-Spoke

Encryption

3DES, AES (256/192/128-bit)

Authentication

MD5, SHA1, SHA2 (256-bit)

Key Managment

IKEv1 (x-auth, mode-config),
IKEv2 (EAP, configuration payload)

VPN Features

Site-to-Site VPN
Client VPN(IPsec/SecuPoint SSL)
Policy-based VPN
IPSec NAT traversal (NAT-T)
Dead Peer Detection (DPD)
Auto-VPN Connection
Auto NAT traversal

Operation mode

Routed / Passthrough

Multiple WANs

Dual

Bandwidth Limit

Per client/ Per Interface

Traffic Load Balancing

WAN load balancing with WRR

Networking Features

Static Route Multiple WANs
USB Cellular
User Authentication
PPPoE
VLAN Tagging
Captive Portal
Custom Splash Page
Dynamic Routing
Bandwidth Limit
Traffic Load Balancing
DHCP client/server/relay
Dynamic DNS support
Policy Based Routing

Security Service

CloudBrink

Environmental & Physical

Power

54V/1.2A

Operation Temperature

0°C to 40°C

Humidity (non-condensing)

5 to 95% non-condensing

Dimensions & Weight

Dimensions

Weight: 2.14 lbs. (0.97k g)
Length: 8.27” (210 mm)
Width: 7.07” (179.5 mm)
Height: 1.38” (35 mm)

Package Contents

Power adapter Power cord
RJ-45 Console Cable
Wall Mount Kit
Product Card

Regulatory Compliance

FCC Part 15 (Class B) IC
CE EMC
CB
UL

Model Comparison

Gateway5 4mG

Gateway6 4mG

Gateway6 8mG 2SFP+

Model Number ESG510 ESG610 ESG620
中央處理器 四核心 四核心 四核心
運行頻率 1.6GHz 2.2GHz 2.2GHz
記憶體 4GB 8GB 8GB (v1);4GB (v2)
快閃儲存 8GB 8GB 16GB
RJ-45 網路埠 4 x 2.5G 4 x 2.5G 8 x 2.5G
PoE供電標準 802.3af/at 802.3af/at 802.3af/at
SFP 光纖模組 - - 2 x SFP+
PoE供電埠 1 1 4
安全晶片 TPM TPM TPM
防火牆(SPI 傳輸能力) 4G 6.8G 7.7G
電源供應 54V/1.2A 54V/1.2A Internal 300w power
VPN傳輸能力 970M 1.5G 1.5G
最多同時VPN連線 200 300 300
安裝方式 Wall mount Wall mount Rack mount
尺寸 210 x 179.5 x 35 mm 210 x 179.5 x 35 mm 330 x 230 x 44 mm
