Multi-Gig 8-Port
VPN Router
The EnGenius ESG620 is a cloud-managed multi-gig secure 8-port VPN Router that delivers advanced firewall protection, high-performance VPN connectivity, and intelligent traffic management for growing business and enterprise networks.
Enterprise Security for High-Performance Networks
The ESG620 combines advanced network security, cloud management, and multi-gig connectivity in a high-performance gateway ideal for enterprises, hospitality, education, healthcare, branch offices, and MSP-managed deployments.
Advanced Network Security
Protect your network with a stateful firewall, IDS/IPS, application control, and advanced threat protection.
Cloud-Managed Networking
Configure, monitor, and manage gateways alongside EnGenius switches and access points through EnGenius Cloud.
High-Speed Multi-Gigabit
Support bandwidth-intensive applications with multi-gig WAN connectivity, VPN acceleration, and intelligent traffic management.
Resources
Access comprehensive documentation, technical guides, and planning tools to accelerate your deployment cycle.
Try Wi-Fi 7 For Free!
Turbo-charge your network with a tri-band access point.
Specifications
Technical
CPU Processor
Quad-Core
Operating Frequency
2.2 GHz
Memory
8 GB
Storage
16 GB
Network Ports (Copper Ports)
8 x 10/100/1000/2500 BASE-T, RJ-45 Ethernet ports
2 SFP+ Ports
Console Port
1 x 10/100/1000, RJ-45 Ethernet port
PoE+ Capable Port
4 (802.3af/at) LAN (P1-P4)
Mounting Method
1U Rackmount 13″
USB Interface
1 x USB 3.0
Security Chip
TPM
Performance & Capacity
Firewall (SPI Throughput)
6.8G* → 9.5G*
VPN Throughput
1.5G* → 1.7G*
Max. TCP Concurrent Sessions
1,000,000
Max. Concurrent VPN Tunnels
300
Max. VLAN
256
Firewall
Firewall Features
Stateful Packet Inspection
Policy Rules
Port Forwarding
1:1 NAT
Allow Inbound Services
Export Outbound and Port Forwarding Rules
Apply firewall rules universally
VPN
Site-to-Site VPN
Mesh VPN/Hub-and-Spoke
Encryption
3DES, AES (256/192/128-bit)
Authentication
MD5, SHA1, SHA2 (256-bit)
Key Management
IKEv1 (x-auth, mode-config)
IKEv2 (EAP, configuration payload)
VPN Features
Site-to-Site VPN
VPN Client – IPSec IKEv1
SecuPoint VPN Client
Policy-based VPN
IPsec NAT traversal (NAT-T)
Dead Peer Detection (DPD)
Auto-VPN Connection
Auto NAT traversal
Networking
Operation Mode
Routed/Passthrough
Multiple WANS
Dual-WAN (WAN 1 SFP+ Fiber & WAN 2 /P7)
WWAN Cellular Backup (USB 3.0)
Bandwidth Limit
Per Interface
Traffic Load Balancing
WAN load balancing with WRR
Networking Features
Static Route
Multiple WANs
USB Cellular
User Authentication
PPPoE
VLAN Tagging
Captive Portal
Custom Splash Page
Dynamic Routing
Bandwidth Limiting
Traffic Load Balancing
DHCP client/server/relay
Dynamic DNS support
Policy Based Routing
Environmental & Physical
Power
54V/1.2A
Operating Temperature
0°C to 40°C
Humidity (non-condensing)
5 to 95% non-condensing
Package Contents
1 x Cloud Managed SD-WAN Gateway
1 x Power cord
1 x RJ-45 Console Cable
1 x Rackmount Kit
Dimensions & Weights
ESG620 Device
Weight: 5.82 lbs. (2.64 kg)
Width: 13” (330 mm)
Length: 9.06” (230 mm)
Height: 1.73” (44 mm)
ESG620 Packaging
Weight: 7.38lbs. (3.35 kg)
Width: 15.43” (392 mm)
Length: 12.20” (310 mm)
Height: 4.05” (103 mm)
Compliance & Warranty
Regulatory Compliance
FCC Part 15 (Class B)
IC
CE EMC (Class B)
RCM
BSMI
Warranty
5 years
Certifications
CE
FCC
IC
