24-Port Non-PoE
Layer 3 Switch
The EnGenius CloudSwitch Core ECS6824F is a cloud-managed Layer 3 fiber switch with 24 × 10G SFP+ ports for high-speed aggregation and core connectivity. It combines advanced Layer 3 routing with enterprise-class reliability, making it ideal for small to mid-sized enterprise deployments.
Scalable Enterprise Core Network Connectivity
The EnGenius ECS6824F delivers high-speed 10G fiber connectivity, advanced Layer 3 routing, and cloud-based management, making it an ideal core and aggregation switch for small to mid-sized enterprise networks.
24×10G Fiber Connectivity
Deliver high-speed 10G fiber connectivity for small to mid-sized enterprise core and aggregation networks.
Advanced Layer 3 Routing
Optimize traffic with dynamic Layer 3 routing, high-performance switching, and intelligent network segmentation.
Flexible Management, Simplified
Manage switches with EnGenius Cloud, Standalone Mode, or remotely via GUI and CLI.
Resources
Access comprehensive documentation, technical guides, and planning tools to accelerate your deployment cycle.
Try Wi-Fi 7 For Free!
Turbo-charge your network with a tri-band access point.
Specifications
Technical
Port Standards
802.3z 1000Base-X
802.3ae 10GBase-R
Network Ports
24 x 10G SFP+ Ports
Console Port
1 x RJ-45 Console port
Management Port
1 x Dedicated Management (MGMT) Port
USB Port
1 x USB 2.0 port
Switching Capacity
480 Gbps
Memory
2GB DDR4 SDRAM
Flash Memory
8 MB SPI NOR Flash + 256 MB NAND Flash
Power Source
AC in
Software Features (L2 Features)
Jumbo Frame
Up to 10K bytes
MAC address Table
Max. 16K
Spanning Tree Protocol
Supports STP, RSTP, and MSTP
Spanning Tree Protocol Feature
Supports PortFast, BPDU Guard, and Root Guard to improve network stability and prevent Layer 2 topology issues.
Port Channel
Supports Static Link Aggregation and LACP (IEEE 802.3ad)
Up to 8 trunk groups
Up to 8 ports per trunk
VLAN
Supports up to 4K IEEE 802.1Q VLANs
Supports GVRP, Voice VLAN, and Surveillance VLAN
LLDP/LLDP-MED
Supports LLDP and LLDP-MED
Port Rate Limiting
Supports bandwidth control based on Tx (Egress) and Rx (Ingress)
Loopback detection
Supports loopback detection to prevent network loops
Software Features (L3 Features)
Routing Table
IPv4: Up to 1,000 routing entries (including up to 512 static routes)
IPv6: Up to 1,500 routing entries (including up to 256 static routes)
IP Interface
Supports up to 128 IPv4 interfaces
Supports up to 128 IPv6 interfaces
ARP Table
Supports up to 4,000 IPv4 ARP entries
Supports up to 8,000 IPv6 Neighbor Discovery entries
Supports configurable ARP aging
Network Diagnostic Tools
Supports IPv4/IPv6 Ping and Traceroute
VRRP
Supports VRRPv2/v3 for gateway redundancy.
L2/L3 Multicast Features
MLD
Supports up to 255 multicast entries (shared with IGMP)
Supports MLD v1/v2
Supports MLD Snooping
IGMP
Supports up to 255 multicast entries (shared with MLD)
Supports IGMP v1/v2/v3
Supports IGMP Snooping
Routing Features
Static Routing
Supports IPv4 and IPv6 Static Routes
RIP/RIPng
Supports RIP; RIPng is not supported
OSPF
Supports OSPFv2 and OSPFv3
Access Control List
Supports IPv4 Standard ACL
Supports IPv4 Extended ACL
Supports IPv6 Standard ACL
Supports IPv6 Extended ACL
Supports MAC ACL
ACL Features
ACL Capacity
Up to 256 ACL entries shared among IPv4 Ingress, IPv4 Egress, and IPv6 Ingress
Up to 512 ACL entries shared among MAC Ingress, MAC Egress, and IPv6 Egress
Access Control List
Supports IPv4 Standard ACL
Supports IPv4 Extended ACL
Supports IPv6 Standard ACL
Supports IPv6 Extended ACL
Supports MAC ACL
QoS
QoS Features
Hardware Queues: 8 queues per port
Traffic Classification: Based on 802.1p Priority and DSCP
Queue Scheduling: Supports Strict Priority (SP) and Weighted Round Robin (WRR)
Bandwidth Control: Supports per-port Ingress (Rx) and Egress (Tx) rate limiting
Management Features
SNMP
Supports IPv4 management
Supports SNMP v1, v2c, and v3
Web UI
Supports HTTP/HTTPS over IPv4 and IPv6
RMON
Supports Statistics (Group 1)
Supports History (Group 2)
Supports Alarms (Group 3)
Supports Events (Group 9)
Port Mirroring
Supports up to 3 mirroring groups
Supports One-to-One and Many-to-One mirroring
NTP
Supports IPv4/IPv6 NTP client
DNS
Supports IPv4/IPv6 DNS client
DHCP Client
Supports IPv4 and IPv6
DHCP relay
Supports IPv4 DHCP Relay
Supports DHCP Option 82
DHCP server
Support IPv4 address
DHCP Snooping
Supports DHCP Option 82
Supports IP Source Guard (IP Filter)
Telnet
Supports IPv4/IPv6 Telnet Client
Supports IPv4/IPv6 Telnet Server
SSH
Supports IPv4/IPv6 SSH Client
Supports IPv4/IPv6 SSH Server
TFTP
Supports IPv4/IPv6 TFTP Client
Dual Image
Supported dual firmware images
Syslog Server
Supports IPv4/IPv6 Syslog Client
EnGenius Cloud management
Supports EnGenius Cloud management
OAM (Operations, Administration, and Maintenance)
Digital Diagnostic Monitoring (DDM)
Supported for compatible optical transceivers
Security Features
Radius
Supports IPv4 RADIUS Client
Storm Control
Supports Broadcast, Multicast, and Unknown Unicast storm suppression
Rate limiting based on Packets Per Second (pps)
IEEE 802.1X Authentication
Supports Port-based and MAC-based authentication.
Supports MAC Authentication Bypass (MAB)
Port Security
Supported port security
DOS protection
Supported protection against ICMP, IP, and TCP DoS attacks
ARP protection
Supports ARP protection
Environmental & Physical
Operating Temperature
0°C to 50°C (32°F to 122°F)
Operating Humidity
10% to 90% RH (non-condensing)
Power Supply
Dual internal AC power supplies (2 × Internal PSU) for power redundancy
Cooling
3 internal cooling fans
Package Contents
1 x Cloud Managed Switch
1 x Product Card
1 x Power Cord
1 x RJ45 Console Cable
1 x Rack Mount Kit
Dimensions & Weights
ECS6824F Device
Weight: 7.93 lbs. (3600 g)
Length: 17.32″ (440 mm)
Width: 10.12″ (257 mm)
Height: 1.73″ (44 mm)
ECS6824F Packaging
Weight: 10.1 lbs. (4580 g)
Length: 21.06″ (535 mm)
Width: 13.77″ (350 mm)
Height: 3.93″ (100 mm)
